    High Speed Mixer
    product name:High Speed Mixer
    category:SHR Series High Speed Mixer
    Product popularity:366
    Updated:2020-01-31 19:50:17
    Inquiry

    product

    High speed mixer is also called heating mixer,  known as heat generated during mixing. It provide multiple components intensive distribution and mixing.

    1. The technology of the main shaft sealed apparatus has got the state patent and it has two functions of electric and steam heating.

    2. Two layers of sealing technology is adopted in the pot cover. The opening of the heating mixed cover adopted the airopening device and the opening of the cooling mixed cover adopted hydraulic pressure control system.

    3. The blades have been passed the test of the dynamic and static balance testing machine.

    4. The electric control section with the programmable logic control adopted wellknown imported meters and control components.

    5. Rapid,perfect after-sales service.

    The main technical parameters:

    Model

    Bowl Volume Total/Effective(L)

    Motor Power(kw)

    Blade Speed(RPM)

    Batch Weight(kg)

    RH300

    300/240

    75/90

    900

    120

    RH500

    500/400

    90/110

    660

    200

    RH600

    600/480

    100/132

    660

    240

    RH800

    800/640

    132/160

    643

    320

    RH1000

    1000/800

    160/200

    610

    400

    RH1200

    1200/960

    200/250

    520

    480

    RH1500

    1500/1200

    250/315

    490

    600

    RH2000

    2000/1600

    315/355

    500

    800
